Product Main Technical Parameters
| Specifications(mm) | ZX6332 | |||
| Max. drilling dia.(mm) | 50 | |||
| Max. end milling width(mm) | 100 | |||
| Max. vertical milling dia.(mm) | 25 | |||
| Max.boring dia.(mm) | 120 | |||
| Max. tapping dia.(mm) | M16 | |||
| Distance from spindle nose to table surface(mm) | 100-480 | |||
| Spindle taper | ISO40 | |||
| Spindle speed range(r.p.m) | 115-1750(V) 40-1300(H) | |||
| Spindle travel(mm) | 120 | |||
| Table size(mm) | 1500x320 | |||
| Table travel(mm) | 800x320/450 Optional: 1000x320/450 | |||
| Table feed speed(mm/min) | X/Y:22-555Z:300 | |||
| Overall dimensions (mm) | 1710x1720x2330 | |||
| Spindle motor power (kw) | 1.5/2.2(V)3(H) | 1.5/2.2(V)3(H) | 1.5/2.2(V)3(H) | |
| Machine weight (kg) | 1250/1350 | 1300/1400 | 1950/2050 | |
