Product Main Technical Parameters
Drilling and Milling Machine Main Performance Characteristics：
Reinforced type gear, transmission torque large
B1 type optional2-speed motor, spindle speed range widely.
Drilling and Milling Machine Application：
Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.
Drilling and Milling Machine Main Technical Specifications:
| Specifications | ZX7045 |
| Max. Drilling capacity (mm) | 45 |
| Max. face mill capacity (mm) | 80 |
| Diameter of vertical milling (mm) | 28 |
| Spindle travel (mm) | 120 |
| Distance spindle axis to column generating line (mm) | 260 |
| Max. Distance spindle nose to table (mm) | 475 |
| Spindle taper | MT4 |
| Spindle speeds range (r/min) | 95～1600 |
| Spindle speeds series | 6 |
| Dimension of worktable surface (mm) | Standard : 730x210 select: 820x240 |
| Table travel (mm) | Standard :450×170 select: 540x170 |
| Overall height (mm) | 1050 |
| Main motor (W) | Single-phase：1100 Three-phase： 1500 |
| G.W/N.W(Kg) | 318/278 |
| Packing dimension (cm) | 97×77×116 |
| Standard accessories | Special accessories |
Drill chuck 16mm, Cutter 80mm, Taper sleeve, Arbor, Drift,Wrench, Drawbar | Milling chuck, Angle vice, Safety guard, Stand |
