C6232D C6236D C6240D Gap Bed Lathe Machine

GSK C6232D, C6236D and C6240D Gap Bed Lathe Machine is a versatile conventional Lathe Machine designed for precision metal turning applications.

Key Features:

High Rigidity Cast Iron Bed
Stable structure with excellent vibration resistance for reliable machining performance.
Wide Machining Capability
Suitable for turning shafts, plates, and various rotating components.
Precision Hardened Guideways
High-frequency quenched guideways improve wear resistance and long-term machining stability.
Easy Operation & Flexible Configuration
User-friendly operation with optional accessories to meet different machining requirements.

Inquire Now Next Product

Features

GSK C series Gap Bed Lathe Machine is a type of conventional Lathe Machine designed for versatile metal turning applications, including internal and external turning, taper turning, drilling, oil groove machining, and cutting metric, module, and inch threads.

The C6232D, C6236D and C6240D Gap Bed Lathe Machines are widely used for machining shafts, plates, and other rotating components in machinery manufacturing, maintenance workshops, and metal processing industries.

Compared with standard lathe machines, the C series features a wider lathe bed structure with high rigidity and excellent stability. The guideways are processed by high-frequency quenching to improve wear resistance and ensure long-term machining accuracy.

The machine is designed with a user-friendly operating system, allowing convenient control and efficient operation. Its rigid structure and optimized transmission system provide reliable cutting performance and effective power utilization during machining processes.

Various optional accessories are available to meet different machining requirements. Before delivery, each machine undergoes comprehensive testing to ensure stable performance, reliable operation, and consistent quality.

Product Main Technical Parameters

Gap Bed Lathe Machine Main Technical Specifications:

Specifications		C6232D	C6236D	C6240D
capacity	Max.Swing over bed	320mm	360mm	400mm
	Max.swing over carriage	180mm	200mm	240mm
	Max.length of workpiece	750/1000mm
	Width of bed	312mm
	Section of turning tool	20x20mm
Spindle	Spindle speeds	30-1600r/min(12 steps)
	Spindle hole	Ø52mm
	Spindle nose	C6
	Spindle taper	MT6
Feed	NO. Of feed	Longitudinal(0.039-1.05mm),cross(0.019-0.52mm)
	Range of metric threads	0.5-20mm(25 kinds)
	Range of inch threads	80-1.75TPI(35 kinds)
	Range of module threads	0.25-10mm
	Range of diametral threads	160-3.5DP(30 kinds)
Tailstock	Max.tailstock spindle travel	100mm
	Tailstock spindle diameter	Ø60mm
	Taper of tailstock	MT4
Main motor		3/4kw
Packing dimensions	Overall dimension for 750mm	2000x1130x1540
	Overall dimension for 1000mm	2250x1130x1540
Weight	Overall dimension for 750mm	1400kg	1500kg	1700kg
	Overall dimension for 1000mm	1500kg	1600kg	1800kg
