Product Main Technical Parameters
Bench Lathe Machine Main Performance Characteristics：
Supersonic frequency hardened bed ways
Precision roller bearing for spindle
High quality steel,ground and hardened gear inside headstock
Easy and fast operating gear box
Enough strong power motor
ASA D4 camlock spindle nose
Various threads cutting functions available
Bench Lathe Machine Main Technical Parameters:
| Specifications | CZ1440G/1 | |||
| Swing over bed | mm | 355 | ||
| Swing over carriage | mm | 220 | ||
| Swing over gap | mm | 500 | ||
| Width of bed-way | mm | 186 | ||
| Distance between centers | mm | 1000 | ||
| Spindle taper | MT5 | |||
| Spindle bore | mm | 38 | 51(Optional) | |
| Step of speed | 8 | 8 | ||
| Range of speed | rpm | 70-2000 | 84-1850 | |
| Head nose | D1-4 | D5 with D5’ chuck | ||
| Metric thread | mm | 26 kinds(0.4-7) | ||
| Inch thread | T.P.I | 34 kinds(4-56) | ||
| Module thread | M.P | 16 kinds(0.35-5) | ||
| Diametral thread | D.P | 36 kinds(6-104) | ||
| Longitudinal feeds | mm/r | 0.052-1.392(0.002’’-0.0548’’) | 0.091-2.533(0.0036’’-0.1005’’) | |
| Cross feeds | mm/r | 0.014-0.38(0.00055’’-0.015’’) | 0.025-0.69(0.0012’’-0.0345) | |
| Diameter of lead screw | mm | 22 | ||
| Pitch of lead screw | 3mm or 8 T.P.I | |||
| Saddle travel | mm | 1000 | ||
| Cross travel | mm | 170 | 160 | |
| Compound travel | mm | 74 | 70 | |
| Barrel travel | mm | 95 | ||
| Barrel diameter | mm | 32 | ||
| Taper of center | mm | MT3 | ||
| Motor power | Kw | 1.5(2HP) | ||
| Coolant motor | Kw | 0.04(0.055HP) | ||
| Machine(L×W×H) | mm | 1920x760x760 | ||
| Stand (left)(L×W×H) | mm | 440x410x700 | ||
| Stand (right)(L×W×H) | mm | 370x410x700 | ||
| Machine(N.W/G.W) | Kg | 505/565 | ||
| Stand(N.W/G.W) | Kg | 70/75 | ||
| Standard accessories: | Optional accessories : |
Stand, 4 jaw chuck, Work lamp, Coolant pump, Brake, Tool post wrench , Inner hexagon spanner , Double end spanner , Screw driver , Center and center sleeve , Change gears , Oil gun , Tool box , Steady rest , Follow rest | Drill chuck, Lead screw guard, Taper shank, Tool post guard, Live centers, Chuck guard, Face plate, Taper turning attachment, |
