CZ1224 CZ1237 Bench Lathe Machine

Inquire Now Next Product

Product Main Technical Parameters

Bench Lathe Machine Main Performance Characteristics：

1.Engineered from high grade castings

2.V way bed ways induction hardened and ground

3.Gap bed

4.Cross and longitudinal interlocking feed, enough safety

5.Inching switch for test running

6.Metric/Imperial threading available

7.Belt-driven headstock,low noise and easy operation

Bench Lathe Machine Main Technical Parameters:

Specifications		CZ1224	CZ1237
Swing over bed	mm	305	305
Swing over carriage	mm	173	173
Swing over gap	mm	440	440
Width of bed-way	mm	182	182
Distance between centers	mm	530	940
Spindle taper		MT5	MT5
Spindle bore	mm	36	36
Step of speed		12	12
Range of speed	rpm	50-1200	50~1200
Metric thread	mm	15 kinds(0.25~7.5)	15 kinds(0.25~7.5)
Inch thread	T.P.I	40 kinds(4~112T.P.I)	40 kinds(4~112T.P.I)
Range of feed amount	Mm/r	0.12~0.42(0.0017’’~0.0165’’)	0.12~0.42(0.0017’’~0.0165’’)
Diameter of lead screw	mm	22(7/8’’)	22(7/8’’)
Pitch of lead screw		3mm or 8 T.P.I	3mm or 8 T.P.I
Saddle travel	mm	510	810
Cross travel	mm	150	150
Compound travel	mm	90	85
Barrel travel	mm	100	95
Barrel diameter	mm	32	32
Taper of center	mm	MT3	MT3
Motor power	Kw	1.1	1.1
Motor for coolant system’s power	Kw	0.04	0.04
Machine(L×W×H)	mm	1420x750x650	1780x750x650
Stand (left)(L×W×H)	mm	400x370x3700	400x370x3700
Stand (right)(L×W×H)	mm	300x370x700	300x370x700
Machine	Kg	365/415	385/435
Machine stand	Kg	60/65	60/65
