Product Main Technical Parameters
| Specifications | Units | B635 |
| Maximum shaping length | mm | 350 |
| Maximum distance from ram bottom to table surface | mm | 330 |
| Maximum moving distance of the working table(level) | mm | 400 |
| Maximum moving distance of the working table (vertical) | mm | 270 |
| Since the plane bed leading surface extending the maximum distance | mm | 550 |
| Maximum ram travel | mm | 170 |
| Table rotary angle (without vice) | ±90° | |
| Table rotary angle (with vice) | ±55° | |
| Maximum tool carrier travel | mm | 110 |
| Number of ram reciprocating per minute | No./min | 32, 50, 80, 125, |
| Gear move one tooth (vertical) | mm | 0.18 |
| Gear move one tooth (level) | mm | 0.21 |
| Gear move four tooth (vertical) | mm | 0.73 |
| Gear move four tooth (level) | mm | 0.84 |
| Main motor power | KWr/min | 1.51400 |
| Overall dimensions (L*W*H) | mm | 1530*930*1370 |
| N/G.W | kg | 1000/1200 |
