VTC650 CNC Vertical Lathe Machine Wholesale

Home > Products > CNC Vertical Lathe Machine

Product Model：

Inquire Now Next Product

Product Main Technical Parameters

	Units	VTC500	VTC650	VTC750	VTC850	VTC1000
Max. Swing diameter	mm	500	650	750	850	1000
Max. Turning diameter	mm	400	550	650	750	850
Spindle Model		A2-8	A2-8	A2-11	A2-11	A2-11
Diameter of spindle bearing	mm	120	120	180	180	180
Spindle speed range	rpm	50-1250	50-1250	50-1000	30-800	30-800
Spindle output torque	nm	350	475	715	890	890
Chuck diameter	〞	12〞HYD液压卡盘	15〞HYD液压卡盘	21〞HYD液压卡盘	24〞HYD液压卡盘	32〞HYD液压卡盘
Turret type		卧式 8 工位 Hor.8 position		卧式8 工位/立式4 工位Hor.8 position / Ver.4 position		立式4 工位
Turret spec		100	100	125	125	125
Tool size	mm	□25/φ40	□25/φ40	□32/φ50	□32/φ50	□32/φ50
Turret travel X axis	mm	-325	-375	-425	-500	-600
Turret travel Z axis	mm	500	550	700	800	800
Distance from Bottom of turret to up of chuck	mm	0-500	0-550	0-700	0-800	0-800
X/Z linear rails		45 滚柱Roller	45 滚柱Roller	55 滚柱Roller	55 滚柱Roller	55 滚柱Roller
Diameter of X/Z screw	mm	φ40	φ40	φ50/φ40	φ50/φ40	φ50/φ40
X-axis rapid traverse	m/min	15	15	15	15	15
Z-axis rapid traverse	m/min	12	12	12	12	12
Cutting feeding	m/min	0.1-5000	0.1-5000	0.1-5000	0.1-5000	0.1-5000
X axis motor power/torque	Kw/nm	1.6/10	2.4/15	2.4/15	2.8/18	3.5/22
Z axis motor power/torque	Kw/nm	2.4/15	2.4/15	2.8/18	3.5/22	3.5/22
Main motor power/torque	Kw/nm	11/15- 140	15/18.5- 190	22/30- 286	30/37- 356	30/37- 356
Overall size (LWH)	m	1.81.82.5	1.951.852.65	2.323	2.52.253.15	2.62.353.15
Machine weight	kg	4200	5200	7200	9500	10500
