Product Main Technical Parameters
Band Saw Machine Main Performance Characteristics：
1. The maximum processing capacity of band saw BS-1018R is 254mm(10”),
2. High-capacity due controlled by motor,
3. The bow can be swiveled between 45°and 90°,
4. Has the advantage of quickly clamping.
5. The falling speed of saw bow is controlled by hydraulic cylinder,
6. With coolant system, can prolong the service life of saw blade and improve the precision of work piece,
7. Is equipped with a block feeder(with fixed sawing length).
Band Saw Machine Application：
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Band Saw Machine Main Technical Parameters:
| Model | BS-1018R | ||
| Machining capacity | Round steel@90° | 254mm(10″) | |
| Square steel@90° | 160x406mm(6.3″×16″) | ||
| Round steel@60° | -- | ||
| Square steel@60° | -- | ||
| Round steel@45° | 170mm(6.7”) | ||
| Square steel@45° | 160×190mm(6.3″×7.5″) | ||
| Saw cutting speeds | @ 60HZ | 35,60,88,115MPM | |
| @ 50HZ | 29,50,73,95MPM | ||
| Saw blade size | 27×0.9×3215mm | ||
| Motor power | 1.5kW 2HP(3PH) | ||
| Drive | V-belt | ||
| Package size | 188×78×134cm | ||
| NW/GW | 320/380kg | ||
