Product Main Technical Parameters
| SPECIFICATIONS | Units | GMC3022 | GMC4022 | GMC5022 |
| Table size（W*L） | mm | 2000*3000 | 2000*4000 | 2000*5000 |
| X axis travel | mm | 3000 | 4000 | 5000 |
| Y axis travel | mm | 2200(副行程Secondary stroke2700) | ||
| Z axis travel | mm | 1000 | 1000 | 1000 |
| Gantry width | mm | 2300 | 2300 | 2300 |
| Gantry passing height | mm | 1400 | 1400 | 1400 |
| Table load | t | 10 | 12 | 14 |
| Distance between spindle nose and table surface | mm | 280～1280 | 280～1280 | 280～1280 |
| T slot(number-width*pitch) | - | 9-28*200 | 9-28*200 | 9-28*200 |
| Spindle taper | - | BT50/200 | BT50/200 | BT50/200 |
| Spindle speed | r/min | 6000 | 6000 | 6000 |
| Rapid traverse speed | m/min | 12 | 12 | 12 |
| Cutting feed speed | m/min | 8 | 8 | 8 |
| Main motor power | kw | 18.5 | 18.5 | 18.5 |
| Tool magazine | 圆盘Arm 30 | 圆盘Arm 30 | 圆盘Arm 30 | |
| Positioning accuracy | mm | X/Y ±0.0075 Z ±0.015 | X/Y ±0.0075 Z ±0.015 | X/Y ±0.0075 Z ±0.015 |
| Repeat positioning accuracy | mm | ±0.005 | ±0.005 | ±0.005 |
| Overall dimension(L*W*H) | mm | 10750*5940*5100 | 12750*5940*510039 | 14750*5940*510039 |
| Machine weight(about) | t | 39 | 43 | 48 |
