Product Main Technical Parameters
| Units | GMC4032 | GMC5032 | GMC6032 | GMC8032 | |
| Table size（W*L） | mm | 2500*4000 | 2500*5000 | 2500*6000 | 2500*8000 |
| X axis travel | mm | 4000 | 5000 | 6000 | 8000 |
| Y axis travel | mm | 200（副行程Secondary stroke3700） | 200（副行程Secondary stroke3700） | 200（副行程Secondary stroke3700） | 200（副行程Secondary stroke3700） |
| Z axis travel | mm | 1250（选配Opt.1500） | 1250（选配Opt.1500） | 1250（选配Opt.1500） | 1250（选配Opt.1500） |
| Gantry width/passing height | mm | W：3200/H：1700 | W：3200/H：1700 | W：3200/H：1700 | W：3200/H：1700 |
| Table load | t | 12 | 15 | 18 | 22 |
| Distance between spindle nose and table surface | mm | 250~1500(可选配加高250、500mm Opt. Heighten 250、500mm） | |||
| T slot(number-width*pitch) | - | 11-28*200（两侧各Two side Each 1-28*180） | |||
| Spindle taper | - | BT50/200 | BT50/200 | BT50/200 | BT50/200 |
| Spindle speed | r/min | 6000 | 6000 | 6000 | 6000 |
| Rapid traverse speed | m/min | 10 | 10 | 8 | 8 |
| Cutting feed speed | m/min | 6-10 | 6-10 | 6-10 | 6-10|
| Main motor power | kw | 18.5 | 18.5 | 18.5 | 18.5 |
| Tool magazine | 圆盘Arm30 | 圆盘Arm30 | 圆盘Arm30 | 圆盘Arm30 | |
| Positioning accuracy | mm | X/Y ±0.0075 Z ±0.015 | X/Y ±0.0075 Z ±0.015 | X/Y ±0.0075 Z ±0.015 | X/Y ±0.0075 Z ±0.015 |
| Repeat positioning accuracy | mm | ±0.005 | ±0.005 | ±0.005 | ±0.005 |
| Overall dimension(L*W*H) | mm | 13440*7770*6770 | 15440*7770*6700 | 17440*7770*6770 | 22240*7770*6770 |
| Machine weight(about) | t | 53 | 59 | 65 | 77 |
