Product Main Technical Parameters
Boring and Milling Machine Main Features：
1.The appearance of beautiful and generous overall layout coordination
2.Fuselage, vertical column, sliding seat are all rectangular guide, good stability
3.Guide rail to take automatic quenching, high wear resistance
4.Gigital synchronous display, intuitive and accurate, can improve the efficiency of low cost
Boring and Milling Machine Application:
1. This machine is suitable for machining the parts of single piece or small batch production in the machine shop.
2. Drilling, boring and hinge hole can be carried out on the machine tool.
Boring and Milling Machine Optional Configuration
Universal boring head
Face milling cutter
Tailstock
Boring bar
3 Axis DRO
Boring and Milling Machine Main Technical Specification:
| Specifications | Units | TX68 |
| Spindle bore | mm | 85 |
| Spindle taper | morse | MT5 |
| Spindle speed | r/min | 25-530(9 steps) |
| Table size (L*W) | mm | 900×800 |
| Table longitudinal travel | mm | 1400 (Without Tailstock) |
| Table cross travel | mm | 700 |
| Spindle box travel | mm | 700 |
| Axial travel of spindle | mm | 300 |
| Table feed speed（steps） | mm/min | 5-160mm/min（6 steps）servo drive |
| Table rapid speed | mm/min | 2000 |
| Spindle box lifting speed | mm/min | 50/400 |
| Spindle motor power | kw | 4 |
| Weight | kg | 5000 |
| Overall dimensions | mm | 2700×1600× 2100 |
